SideKick Cryogenic Systems

View of cold plate

Ultra-High Vacuum. Low Vibrations. Low Temperature

The SideKick systems mount the cryocooler directly to the floor, leaving the optics table quiet and open. Differential sealing enables superior vacuum performance .

This series mounts the cryocooler directly to the floor, removing energy and freeing up table space

system features

Vibrations shunted to floor

Vibrations shunted to floor

Vibrations shunted to floor

Sample chamber and mounting pillar

UHV Cryogenic workspace integrated directly into existing optical setups. Cryocooler energy is shunted away from table into the floor. Works with 12" to 37" thick

optical tables

Versatile Access

Vibrations shunted to floor

Vibrations shunted to floor

Assembling the chamber

System includes 24 DC connections standard, six industry standard ISO63 ports available for more RF, DC, or fiber optics, and nine optical access ports (8 horizontal, 1 on top)

UHV Performance

Vibrations shunted to floor

Large cold space

Top view of cold plate

Novel integrated differential pumping seal design (double Oring) for maximum vacuum performance while maintaining easy access to inner sample space. All low outgassing (UHV approved) materials and 150°C bake out.

Large cold space

Maximum Configurability

Large cold space

Cold plate with RF and DC interface connections

200mm diameter cold sample plate with four cold interface panels for RF, DC, or fiber optics. Optional 250mm cold plate with eight cold interface panels.

Maximum Configurability

Maximum Configurability

Maximum Configurability

Radiation shield with windows

Flexible chamber and workspace to fit any application. Standardized side ports and interface options. 100mm tall sample space shown; taller space is available for applications with nanopositioners or low vibe insert for ultra-low vibration applications.

Easily Customizable

Maximum Configurability

Maximum Configurability

Sample chamber and interface flanges

Flexible chamber and workspace to fit any application. 100mm tall sample space shown; taller space is available for applications with nanopositioners or low vibe insert for Scanning Probe Microscope.

Specifications

SK100

  • Base Temperature    < 4K
  • Cooling Power       100mW @ 5K
  • Peak-to-Peak Vibrations    < 15nm
  • Room Temperature Vacuum, before cryopumping 1E-8 Torr      (after bake) and 1E-11 Torr once cold

SK200

  • Base Temperature    < 3.6K
  • Cooling Power       200mW @ 5K
  • Peak-to-Peak Vibrations    < 25nm
  • Room Temperature Vacuum, before cryopumping 1E-8 Torr      (after bake) and 1E-11 Torr once cold

SK300

  • Base Temperature    < 3.5K
  • Cooling Power       300mW @ 5K
  • Peak-to-Peak Vibrations    < 30nm
  • Room Temperature Vacuum, before cryopumping 1E-8 Torr      (after bake) and 1E-11 Torr once cold

Options

Micro D25 feedthroughs

Additional DC Feedthroughs

SMA RF coax feedthroughs

SMA (floating) RF Feedthroughs

Coax vacuum feedthroughs

SMP RF Feedthroughs

Contact us for more information on custom options.

Photo Gallery

200 mm diameter cold plate. Image shows four interface strips, in this case configured for RF and digital connections.

    Downloads

    Sidekick data sheet web (pdf)Download
